ETFE Fluoropolymer FILM

Product Center

넳 넲

ETFE film is a transparent, thermoplastic film that can be heat sealed, thermoformed, vacuum formed, heat bonded, welded, metalized, laminated(combined with dozens of other materials), and used as an excellent hot melt adhesive. This wide variety of fabrication possibilities combines with the following important properties to offer unique balance of capabilities not available in other plastic films.





Product Feature:




Heat Resistance

 ·  Continuous service temperature : -100 to 150℃(-148 to 300℉).

 ·  Melting range: 250 to 270℃（482 to 518℉）

 ·  Heat sealable



Chemical Resistance:

·  ETFE film is stable to almost all chemicals and solvents.

·  It also has low permeability to liquids, gases, moisture, and organic vapors.



Flame Resistance

 · ETFE films is flame retardant material with limited oxygen index (LOI) >30%.



Weather Resistance:

 · Excellent Weather resistance,  will not cause surface contamination, oxidation, discoloration, poor quality and other situations.

 · High transmittance of ultraviolet and all, but far, infrared.



Mechanical Toughness

 · Superior anti-stick and low frictional properties.

 · High resistance to impact and tearing.



 Table 1: Typical Properties of QMT ETFE Fluoropolymer Film:

Items

Unit

Value

Gauge

μm

12.5-500

Width

mm

50-1600

Density

g/cm3

1.7

Melt Point

℃

250-270

Continuous Service Temperature

℃

150

Tensile Strength(MD/TD)

Mpa

67/66

Elongation at break (MD/TD)

%

430/480

*Tested by premium series 50 micron ETFE film

  • ETFE Fluoropolymer FILM

    ETFE film is a transparent, thermoplastic film that can be heat sealed, thermoformed, vacuum formed, heat bonded, welded, metalized, laminated(combined with dozens of other materials), and used as an excellent hot melt adhesive. This wide variety of fabrication possibilities combines with the following important properties to offer unique balance of capabilities not available in other plastic films.

    넶4 ¥ 0.00

  • FEP Fluoropolymer FILM

    Offering excellent heat resistance, non-stick and electrical performance
    Applications:
    Electronic industry release film, welding film, carbon fiber molding isolation film, acoustic film, cable wrapping.

    넶17 ¥ 0.00

  • PFA Fluoropolymer FILM

    PFA film is a transparent, thermoplastic film that can be heat sealed, thermoformed, vacuum formed, heat bonded, welded, metalized, laminated (combined with dozens of other materials), and used as an excellent hot-melt adhesive. This wide variety of fabrication possibilities combines with the following important properties to offer a unique balance of capabilities not available in any other plastic film.

    넶4 ¥ 0.00

  • ECTFE Fluoropolymer Film

    ECTFE film is made of ECTEF resin as raw material through melt extrusion. Its surface is smooth and the product has excellent performance in all aspects. Because of its outstanding tear resistance and water vapor barrier properties, it is very suitable for use in photovoltaic front panel coating and constrictions field.

    넶5 ¥ 0.00

  • PCTFE Fluoropolymer Film

    PCTFE film is a transparent, thermoplastic film that can be heat sealed, thermoformed, vacuum formed, heat bonded, welded, metalized, laminated (combined with dozens of other materials), and used as an excellent hot-melt adhesive. This wide variety of fabrication possibilities combines with the following important properties to offer a unique balance of capabilities not available in any other plastic film.

    넶4 ¥ 0.00

  • tailor made product

    The company can process the surface treatment of ETFE, FEP, PFA, ECTFE, and PCTFE films according to customer needs to improve the bonding performance of the film with other materials.

    넶3 ¥ 0.00
